SELF CONTAINED
SUMMARY
Universal Handling Packer Roll Off Combination container is the ideal solution for processing waste that prevents contact with the waste once it has passed through the ram cycle. Ideal for multiple applications like hospitals, food processing plants, restaurants, hotels and shopping malls.
- Leak resistant tailgate
- Lightweight/high strength design for increased legal payloads
- Packer mounted or remote power units
- Portable easily relocated
- Reduced installation costs
- Fully adaptable to most applications
- Multi function control panel
- No limit switches
SPECIFICATION & DATA
Specifications
| MFR Rating | 2 cu/yrd |
| NSWMA Rating | 1.5 cu/yrd |
| Charging Opening | 60"W x 40 1/2"L |
| Charge Box Depth | 34" |
| Ram Face | 59 5/8"W x 30"H |
| Ram Penetration | 5" |
Performance
| Cycle Time | 45 sec |
| System Pressure Normal | 1,750 PSI |
| System Pressure Maximum | 2,000 PSI |
| Ram Force Rating Normal | 34,360 lbs |
| Ram Force Rating Maximum | 39,270 lbs |
Hydraulics/Electrical
| Reservoir Capacity | 28 gal |
| Cylinder Stroke | 42 3/8" |
| Cylinder Rod | 2 1/2" |
| Cylinder Bore | 5" |
| Motor Voltage/Size | 208-600V 10 HP |
Structure
| Floor | 3/8" |
| Ram Face | 3/8" |
| Side Walls | 1/4" |
Specification data on this website is provided for informational purposes and is not guaranteed to be accurate, may contain errors, and is subject to change without notice.
OPTIONS
Design
- Special widemouth configuration
- Cabinet or Through wall hoppers
- Two way pick-up
- Free standing or packer mounted dump units
Electrical
- 3/4 full light
- Safety interlocks
- Tank heater
- In floor heating
- Upgrade to 15 or 20 HP
Painting
- Wide arrange of available paint colours
- Will match customer sample when provided
